# Playing the Double Base

Here’s some mathematical nonsense:

10 > 12

100 > 122

1000 > 1222

How can 1000 > 1222? Well, it makes perfect sense in what you might call a double base. In this base, every number is identified by a unique string of digits, but the strings don’t behave as they do in a standard base.

To see how this double base works, first look at 9 in standard base 2. To generate the binary digits from right to left, you follow the procedure x mod 2 and x = x div 2, where (x mod 2) returns the remainder when x is divided by 2 and (x div 2) divides x by 2 and discards the remainder:

9 mod 2 = 1 → ...1

9 div 2 = 4

4 mod 2 = 0 → ..01

4 div 2 = 2

2 mod 2 = 0 → .001

2 div 2 = 1

1 mod 2 = 1 → 1001

So 9_{[b=10]} = 1001_{[b=2]}. To adapt the procedure to base 3, simply use x mod 3 and x = x div 3:

32 mod 3 = 2 → ...2

32 div 3 = 10

10 mod 3 = 1 → ..12

10 div 3 = 3

3 mod 3 = 0 → .012

3 div 3 = 1

1 mod 3 = 1 → 1012

So 32_{[b=10]} = 1012_{[b=3]}.

But what happens if you mix bases and use (x mod 3) and (x div 2), like this?:

2 mod 3 = 2 → .2

2 div 2 = 1

1 mod 3 = 1 → 12

3 mod 3 = 0 → .0

3 div 2 = 1

1 mod 3 = 1 → 10

So 10 > 12, i.e. 10_{[b=3,2]} > 12_{[b=3,2]}.

5 mod 3 = 2 → ..2

5 div 2 = 2

2 mod 3 = 2 → .22

2 div 2 = 1

1 mod 3 = 1 → 122

6 mod 3 = 0 → ..0

6 div 2 = 3

3 mod 3 = 0 → .00

3 div 2 = 1

1 mod 3 = 1 → 100

So 100 > 122.

11 mod 3 = 2 → ...2

11 div 2 = 5

5 mod 3 = 2 → ..22

5 div 2 = 2

2 mod 3 = 2 → .222

2 div 2 = 1

1 mod 3 = 1 → 1222

12 mod 3 = 0 → …0

12 div 2 = 6

6 mod 3 = 0 → ..00

6 div 2 = 3

3 mod 3 = 0 → .000

3 div 2 = 1

1 mod 3 = 1 → 1000

And 1000 > 1222. Here are numbers 1 to 32 in this double base:

1 = 1

12 = 2

10 = 3

121 = 4

122 = 5

100 = 6

101 = 7

1212 = 8

1210 = 9

1221 = 10

1222 = 11

1000 = 12

1001 = 13

1012 = 14

1010 = 15

12121 = 16

12122 = 17

12100 = 18

12101 = 19

12212 = 20

12210 = 21

12221 = 22

12222 = 23

10000 = 24

10001 = 25

10012 = 26

10010 = 27

10121 = 28

10122 = 29

10100 = 30

10101 = 31

121212 = 32

Given a number represented in this mixed base, how do you extract the underlying n? Suppose the number takes the form n = (digit[1]..digit[di]), where digit[1] is the first and leftmost digit and digit[di] the final and rightmost digit. Then this algorithm will extract n:

n = 1

for i = 2 to di

..n = n * 2

..while n mod 3 ≠ digit[i]

....n = n + 1

..endwhile

next i

print n

For example, suppose n = 12212_{[b=3,2]}. Then di = 5 and the algorithm will work like this:

n = 1

n = n * 2 = 2.

2 mod 3 = 2 = digit[2]

2 * 2 = 4

4 mod 3 = 1 ≠ digit[3]

5 mod 3 = 2 = digit[3]

5 * 2 = 10

10 mod 3 = 1 = digit[4]

10 * 2 = 20

20 mod 3 = 2 = digit[5]

Therefore 12212_{[b=3,2]} = 20_{[b=10]}.

Now try some more mathematical nonsense:

21 > 100

111 > 1,000

1,001 > 10,000

10,001 > 100,000

How can numbers with d digits be greater than numbers with d+1 digits? Easily. In this incremental base, the base adjusts itself as the digits are generated, like this:

5 mod 2 = 1 → .1

5 div 2 = 2

2 mod (2 + 1) = 2 mod 3 = 2 → 21

The first digit generated is 1, so the base increases to (2 + 1) = 3 for the second digit. Compare the procedure when n = 4:

4 mod 2 = 0 → ..0

4 div 2 = 2

2 mod 2 = 0 → .00

2 div 2 = 1

1 mod 2 = 1 → 100

So 21 > 100, because 4 is a power of 2 and all the digits generated by (x mod 2) are 0 except the final and leftmost. 2 + 0 = 2. Now try n = 33:

33 mod 2 = 1 → ...1

33 div 2 = 16

16 mod (2+1) = 16 mod 3 = 1 → ..11

16 div 3 = 5

5 mod (3+1) = 5 mod 4 = 1 → .111

5 div 4 = 1

1 mod (4+1) = 1 mod 5 = 1.

33_{[b=10]} = 1111_{[b=2,3,4,5]}.

Here are numbers 1 to 60 in this incremental base (note how 21 > 100, 111 > 1000, 1001 > 10000 and 10001 > 100000):

1 = 1

10 = 2

11 = 3

100 = 4*

21 = 5*

110 = 6

101 = 7

1000 = 8*

111 = 9*

210 = 10

121 = 11

1100 = 12

201 = 13

1010 = 14

211 = 15

10000 = 16*

221 = 17

1110 = 18

1001 = 19*

2100 = 20

311 = 21

1210 = 22

321 = 23

11000 = 24

1101 = 25

2010 = 26

1011 = 27

10100 = 28

421 = 29

2110 = 30

1201 = 31

100000 = 32*

1111 = 33

2210 = 34

1021 = 35

11100 = 36

2001 = 37

10010 = 38

1211 = 39

21000 = 40

1121 = 41

3110 = 42

2101 = 43

12100 = 44

1311 = 45

3210 = 46

1221 = 47

110000 = 48

2201 = 49

11010 = 50

2011 = 51

20100 = 52

1321 = 53

10110 = 54

10001 = 55*

101000 = 56

2111 = 57

4210 = 58

1421 = 59

21100 = 60

And here are numbers 256 to 270 (Note how 8,421 > 202,100 > 100,000,000):

100000000 = 256*

11221 = 257

101110 = 258

32101 = 259

202100 = 260*

13311 = 261

41210 = 262

10321 = 263

1111000 = 264

24201 = 265

131010 = 266

23011 = 267

320100 = 268

8421 = 269*

52110 = 270

Extracting n from a number represented in this incremental base is trickier than for the double base using (x mod 3) and (x div 2). To see how to do it, examine 11221_{[b=incremental]}. The fifth and rightmost digit is 1, so the base increases to (2 + 1) = 3 for the fourth digit, which is 2. The base increases to (3 + 2) = 5 for the third digit, which is 2 again. The base increases to (5 + 2) = 7 for the second digit, 1. But the first and rightmost digit, 1, represents (x div 7) mod (7 + 1 = 8). So n can be extracted like this:

digit[1] * 7 = 1 * 7 = 7

7 mod 7 = 0 ≠ digit[2]

8 mod 7 = 1 = digit[2]

8 * 5 = 40

40 mod 5 = 0 ≠ digit[3]

41 mod 5 = 1 ≠ digit[3]

42 mod 5 = 2 = digit[3]

42 * 3 = 126

126 mod 3 = 0 ≠ digit[4]

127 mod 3 = 1 ≠ digit[4]

128 mod 3 = 2 = digit[4]

128 * 2 = 256

256 mod 2 = 0 ≠ digit[5]

257 mod 2 = 1 = digit[5]

So 11221_{[b=8,7,5,3,2]} = 257_{[b=10]}.

Now try 8421_{[b=incremental]}. The fourth and rightmost digit is 1, so the base increases to (2 + 1) = 3 for the third digit, which is 2. The base increases to (3 + 2) = 5 for the second digit, 4. But the first and rightmost digit, 8, represents (x div 5) mod (5 + 4 = 9). So n can be extracted like this:

digit[1] * 5 = 8 * 5 = 40

40 mod 5 = 0 ≠ digit[2]

41 mod 5 = 1 ≠ digit[2]

42 mod 5 = 2 ≠ digit[2]

43 mod 5 = 3 ≠ digit[2]

44 mod 5 = 4 = digit[2]

44 * 3 = 132

132 mod 3 = 0 ≠ digit[3]

133 mod 3 = 1 ≠ digit[3]

134 mod 3 = 2 = digit[3]

134 * 2 = 268

268 mod 2 = 0 ≠ digit[4]

269 mod 2 = 1 = digit[4]

So 8421_{[b=9,5,3,2]} = 269_{[b=10]}.
